Certification EPA EEC Approved
Engine Type
4-stroke, Single-Cylinder, Air/Oil-cooled
Displacement 149.6cc
Max Power 6.8Kw/7500r/min
Max Torque
Valve Configuration SOHC
Compression Ratio 9.0:1
Top Speed 34.2 MPH

Fuel System

Fuel Delivery System Carburetor
Choke System Automatic
Fuel Capacity 2.1 Gallons

Drive Train

Driveline Type 2WD
Final Drive Chain Drive
Transmission CVT
Gear Selection Forward and Reverse Single Speed

Electrical System

Forward Lights Headlights - High Beam and Low Beam
Rear Lights Brake Lights and Left/Right Signal Lights
Starting System Electric Start
Ignition System C.D.I


Front Suspension Dual Top and Bottom A-Arms
Rear Suspension Dual Top and Bottom A-Arms


Front Brakes Dual Hydraulic Disk
Rear Brakes Single Axle Hydraulic Disk


Front Tires 19x7-8, 40 Inche (1020 MM)
Rear Tires 20x10-9, 38 Inch (965 MM)

Measurements and Dimensions

Special Pricing

Use the form below to get access to exclusive pricing.
Dry Weight 540 lbs
Shipping Weight 660 lbs
Wheelbase 65 Inches
Vehicle Dimensions 88.6"(L) x 48"(W) x 55"(H)
Packing Size 90.2"(L) x 51.2"(H) x 32.1"(W)
Ground Clearance 6 Inches

Special Features and Included Accessories

Full Windshield Included
Vinyl Roof Included
Rearview Mirrors Included
Door Nets Included
Driver/Passenger Seatbelts Included
Passenger Grab Bar Included
